Features
- Test at any angle, even upside down.
- User calibration function.
- Auto power off to save energy.
- USB port with the PC humanity multi-functions data proceeding software.
- Battery information indicates the rest capacity of the battery and the charge status.
- Upper and lower limits can be preset. It will alarm automatically when the result value exceeds the limit.
- Seven impact devices are available for special application
Technical Specifications
| Measuring direction | 360° |
| Hardness Scale | HL, HB, HRB, HRC, HRA, HV, HS |
| Display | Dot matrix LCD, 128 × 64 dots |
| Data memory | 100 to max 600 groups. (Relative to impact times 32 to 1) |
| Printing paper | width is (57.5 mm ± 0.5 mm), diameter is 30mm |
| Battery pack | 6 V NI-MH |
| Battery charger | 9 V/ 500 mA. |
| Continuous working period | about 200 hours (With backlight off, no printing) |
| Interface | USB 2.0 |
Click Here to Download Technical
Documentation (User Manual or Instruction Manual)
