Features
- ISO, CE, FCC, ROHS, ATEX, CNEX, SIL3 Approved
- IR controller for remote operation for 15 meters distance
- Automatic zero-point calibration function
- Upto 5 level calibration points
- Setting recovery function
- LED display
- Aluminum enclosure, support 304 or 316L stainless steel
- Detection method: diffusion
- Standard output: RS485, 4-20mA & Rely
- Optional output: LoRa, NB-IOT wireless transfer
- Standard with computer software for data collection, analysis and export
- Support sensor type: NDIR, EC, TCD, MOS, LEL and etc.
- Installation: wall-mounted, pipeline or flange
Technical Specifications
| Parameters | Details |
| Single Gas Detector | (Combustible Gas) |
| Detection Principle | Catalytic Combustion Sensor |
| Measuring Range | 0–100% LEL |
| Resolution | 1% LEL |
| Accuracy | ≤ ±3% (F.S) |
| Response Time (T90) | ≤ 30 seconds |
| Sensor Lifetime | 2–3 years |
| Detection Method | Diffusion type |
| Installation | Wall-mounted |
| Output Type | RS485, 4–20mA |
| Power Supply | 24VDC ±5%, <4W |
| Protection Level | IP67 |
| Product Size | 197 × 202 × 88 mm |
| Weight | 1.5 kg (Aluminium enclosure) |
| Explosion Protection Grade | Ex db II C T6 Gb |
| Electrical Interface | 3/4 NPT |
| Alarm Mode | LED display + Sound & Light Alarm |
| Working Environment | -20℃ to +55℃, 10–95% RH (non-condensing) |
