Key Features
- LED Backlight
- Automatic power off after 5 minutes
- Portable, light and compact
- Easy interface
Technical Specifications
| Measuring range | HLD(170~960)HLD |
| Measuring direction | 0°~360° |
| Hardness Scale | HL,HB,HRB,HRC,HRA,HV,HS |
| Display | segment LCD |
| Data memory | 100 groups max.(relative to impact times 32~1) |
| Printing paper | width is (57.5±0.5)mm, diameter is 30mm. |
| Battery pack | 6V NIMH |
| Battery charger | 9V/500mA
Continuous working period;about 150 hours(With backlight off, no printing) |
| Communication interface; | USB1.1 |
| Outline dimensions | 212mm×80mm×32mm / 8.35×3.15×1.26in |
