Overview
Enviro Forest IoT people counting sensor for Indoor Workplaces, based on Artificial Intelligence technology, is an AI workplace sensor designed to monitor occupancy and utilization in modern workspaces. It can reach up to 95% recognition rate and sense from up to 78 m², requiring fewer sensors to cover the same area, thus reducing deployment costs for users. Only counter values are transmitted over the Lora WAN network, which prevents privacy concerns.
Technical Specifications
| Lora WAN | Protocol | Lora WAN v1.0.2 / v1.0.3 / v1.1 |
| Frequency | CN470 / IN865 / RU864/ EU868 / US915 / AU915 / KR920 / AS923 | |
| Tx Power | 16 dBm (868 MHz) / 22 dBm (915 MHz) / 19 dBm (470 MHz) | |
| Sensitivity | 137 dBm at 300bps | |
| Mode | OTAA / ABP Class A | |
| People Counting | Field of View | 112 ° Horizontal 190 ° Vertical |
| Detection Range | 19.6 ft x 26.2 ft = 157.4 ft2 (At the height of 9.84 ft) (6 m × 8 m = 48 m²) (At the height of 3 m) | |
| Detection Accuracy | > 95 % | |
| Advanced Custom Setting | Up to 12 mapped regions for detection | |
| Interface | Wi-Fi | IEEE 802.11 b/g/n 2.4GHz only support configuration |
| Button | 1 × Reset Button 1 × Wi-Fi Button | |
| LED Indicators | 1 × Wi-Fi | |
| Power Input | 1 × Type-C | |
| Physical Characteristics | Power Supply | 5 V / 1.5 A by Type-C Port |
| Color | Black/White (Optional) | |
| Installation | Ceiling Mounting | |
| Relative Humidity | 0 % to 95 % (non-condensing) | |
| Operating Temperature | 23 ° F to 131 ° F (- 5 °C to + 55 °C) | |
| Storage Temperature | 4 ° F to 140 ° F (- 20 °C to + 60°C) | |
| Dimension | 3.35 in × 3.35 in × 0.79 in (85 mm × 85 mm × 20 mm) |
