Technical Specifications
| NH4 Specification | |
| Measuring Range | 0mg or L to 1000 mg or L (ppm) Slope reading 70% to 130% Zero potential -50 mv to 50 mv |
| Accuracy | ±5% reading ±0.5 mg or L |
| Resolution | 0.01 mg or L |
| Reproducibility | ±3% reading ± 0.5 mg or L |
| Electrodes Withstand Voltage | Max. 50 Psig |
| Operating Temperature | 32 °F to 104 °F(0 °C to 40°C) |
| Communication | RS 485 Modbus RTU Wi-Fi Modbus TCP Web Browser direct reading (192.168.1.80) |
| Certificate | CE, FCC |
| Temperature Specification | |
| Measuring Range | 14 °F to 248 °F (-10 °C to 120 °C) (ATC) |
| Accuracy | ±0.36 °F (±0.2 °C) |
| Resolution | 0.18 °F (0.1 °C) |
| Reproducibility | 0.18 °F (0.1 °C) |
| Other Specification | |
| Link Below | 3 NPT or 4” NPT |
| Link Below | M 42 |
| Housing Material | PP, acid and alkali resistance or food grade or zero dissolution |
| Power | 12 VDC (auto-cleaning) 9 VDC to 36 VDC (Non-auto-cleaning) |
| Power Consumption | 1.6 w (auto-cleaning) 0.8 w (non-auto-cleaning) |
| Line Length | 3 |
| Ingress Protection Rating | IP68 |
| Temperature Principle | NTC30K |
| Dimension | 1.77 in × 8.4 in (45 mm x L214 mm) |
| Weight | 0.75 lb(≤ 0.340 kg) |
