| Measuring range |
0 ppm to 10000 ppm ×10-6 ppm vol, CO: 0% vol to 10% vol ×10-2 % volCO2: 0% vol to 20% vol ×10-2 % vol, O2: 0% vol to 25% vol ×10-2 % vol |
| R.M.P |
0 r.m.p to 9999 r.m.p |
| OIL TEMP |
32 to 302 (0 ℃ to 150 ℃) |
| Repeatability |
≤±2% |
| Stability: moment drift |
≤±3% |
| Resolution |
1 × 10^-6 (ppm) vol, CO: 0.01% vol × 10^-2% vol, CO2: 0.1% vol × 10^-2% vol. |
| Response time |
95% response is not more than 10 seconds |
| Preheating time |
8min (preheating 3min emergency detection) |
| Output mode |
Output mode can display, and print gas concentration maximum value, average value, the minimum value of the license plate number, test time, date, speed, temperature, and COcor value of lambda, and can interface with computer networking |
| Temperature, Relative humidity |
23 to 122 -5°C to 50°C), ≤90% RH |
| Power |
AC 100 V to 240 V,50 Hz to 60 Hz, or DC 12 V (Add power inverter) |
| Power consumption |
40 VA |
| Dimension |
16.54 in x 12.20 in x 6.69 in (420 mm ×310 mm × 170 mm) |
| Weight |
19.84 lb (9 kg) |
