Features
- The ion instrument is used in industrial measuring
- It can be panel, wall or pipe mounted
- The ion meter provides two current outputs
- It can pass through a maximum of 5 A
- It has data logger function
- It’s automatic to change unit different ion sensor
Technical Specifications
| Functions | ION (F-, Cl-, Mg2+, Ca2+, NO3-, NH+) |
| Measuring Range | 0.00 ppm to 5000 ppm |
| Resolution | 0.01 ppm (<1 ppm), 0.1 ppm (<10 ppm), 1 (others) |
| Accuracy | ± 0.01 ppm, ± 0.1 ppm, ± 1 ppm |
| Mv Input Range | 0.00 mV to 1000.00 mV |
| Input Impedance | >1012Ω |
| ION Current Output1 | Isolated, 4 mA to 20 mA output, max. load 500Ω |
| Temp. Current Output 2 | Isolated, 4 mA to 20 mA output, max. load 500Ω |
| Current Output Accuracy | ±0.05 mA |
| Rs485 | ModBus RTU protocol |
| Baud Rate | 9600 or 19200 or 38400 |
| Cleaning Setting | ON: 1 s to 1000 s, OFF: 0.1 h to 1000.0 h |
| One Multi Function Relay | Clean or Period Alarm or Error Alarm |
| Data Logging Capacity | 500.000 |
| Waterproof Grade | IP65 |
| Installation | Panel or Wall or Pipe Installation |
| Maximum Relay Contacts Capacity |
5 A or 250 V AC, 5 A or 30 V DC |
| Relay Delay | 0 s to 120 s |
| Power Supply | From 90 V AC to 260 V AC, Power Consumption < 5 W |
| Temp. Compensation | Pt 1000 or NTC10 K |
| Temp. Range | -50 °F to + 86 °F (-10 °C to +30 °C) |
| Temp. Compensation Range | -50 °F to +86 °F (-10 °C to +30 °C) |
| Temp. Resolution | 33.8 °F (0.1 °C) |
| Temp. Accuracy | ± 35.6 °F (± 0.2 °C) |
| Ambient Temperature Range | 32 °F to 158 °F (0 °C to 70 °C) |
| Storage Temp. | 68 °F to +158 °F (-20 °C to +70 °C) |
