Overview
Enviro Forest digital micro–ohm meter can measure the resistance value on the object’s surface by putting two parallel electrodes close to the object’s surface to be measured, to judge whether the measured object is a conductor, static material, or insulator, meanwhile, the meter can be used to measure the resistance to ground of object, which is specially applied to different antistatic fields. Also, the unit can measure the environment temperature for your reference.
Technical Specification
| Measuring Range | 10 ^ (3) Ω to 10 ^ (12) Ω |
| Testing Voltage | 9 V |
| Display Type | Digital Only |
| Accuracy Class | ± 10 % (100 K to 10 G) |
| resistance range | 10 ^ (3) Ω to 10 ^ (12) Ω |
| Temperature accuracy | ± 2 % |
| Operation humidity | 10 RH % to 70 RH % |
| Display type | segment type big LCD with back light |
| Power supply | 9 V battery |
| Temperature range | 32 °F to 122 °F (0 °C to 50 C) |
| Operation temperature | 32 °F to 122 °F (0 °C to 50 C) |
| Dimensions | 5.9 in x 2.36 in x 1.18 in (150 mm x 60 mm x 30 mm) |
