Features
- Equipped with a large backlit LCD
- 1 or 2 points calibration using the air saturated water or zero oxygen solution
- Salinity and barometric pressure compensations ensure the reliable measuring results
- Automatic Temperature Compensation provides accurate reading over the entire range
- Calibration Due Alarm prompts user to calibrate the meter regularly
- Stability indicator shows when a measurement is recognized as stable
- Auto hold feature senses and locks the measurement endpoint
- Setup menu allows setting the 9 parameters
- Reset feature automatically resumes all settings back to factory default options
- Expanded memory stores and recalls up to 500 data sets
- Stored readings can be transferred into the computer by USB communication interface
Technical Specifications
| Dissolved Oxygen | |
| Range | 0.00 mg/L to 20.00 mg/L |
| Accuracy | ± 0.2 mg/L |
| Resolution | 0.01 mg/L, 0.1 mg/L, selectable |
| % Saturation of Oxygen | |
| Range | 0.0 % to 200 % |
| Accuracy | ± 2.0 % |
| Resolution | 0.1 %, 1 % |
| General | |
| Calibration Points | 1 or 2 points |
| Pressure Correction | 60.0 kPa to 112.5 kPa, 450 mmHg to 850 mmHg |
| Salinity Correction | 0 g/L to 50g/L |
| Data Hold | Manual or Auto endpoint |
| Stability Criteria | Low or high |
| Calibration Due Alarm | 1 to 31 days or Off |
| Power Off | Manual or Automatic (10, 20, 30 minutes) |
| Memory | Stores up to 500 data sets |
| Output | USB communication interface |
| Connector | 6 pin mini plug |
| Display | LCD |
| Power | DC5V, using AC adapter, 220 vac or 50 Hz |
| Temperature Compensation | 32 °F to 122 °F (0 °C to 50 °C), Automatic |
| Dimensions | 8.26 in x 7.40 in x 2.36 in (210 mm x 188 mm x 60 mm) |
| Weight | 3.30 lb (1.5 kg) |
