Features
- Different storage intervals can be set
- Cooperate with powerful data management software
- Small size, light weight, easy to carry
Technical Specifications
| TTR measurement range | 0.8 to 10000 |
| High measurement speed | High measurement speed |
| Voltage measurement accuracy on HV side | 0.05% |
| Voltage measurement accuracy on LV side | 0.1% |
| Phase angle measurement accuracy | 0.1° |
| TTR measurement accuracy | 0.1% (0.8 to 3000) 0.2% (3000 to 10000) |
| Weight | (3 kg) |
| Working temperature | 14 °F to 104 °F (-10 ℃ to 40 ℃) |
| Charging power | AC 220 V, frequency 45 Hz to 55 Hz |
| Host power consumption | ≤3 VA |
| Maximum working time of the battery | ≤10 hours |
| Dimensions | 10.2 in x 6.3 in x 2.4 in (260 mm × 160 mm × 60 mm) |
