Features
- With relay output 10 A, can drive ventilator or solenoid valve
- Monitor gas concentration in open air in the environment
- Two stage alarm with sound and light
- Explosion proof design, proof grade Ex dII CT6, IP65 water dust proof
- LED display, Independent acousto-optic alarm, need extra cost $15 per pc
- With zero calibration functions, makes the detection more accurate
- With 4 mA to 20 mA signal output, being compatible with PLC, DCS
Technical Specifications
| Measurable Gas | Combustible gas, toxic and harmful gas |
| Sampling | Natural diffusion |
| Battery | 24 V DC or 36 V DC ±10 % |
| Power | 12 V DC to 30 V DC |
| Output Signal (The User Can Decide As Follows According To Actual Needs) | A. Standard three-wire 4 ma to 20 ma analog signal output B. Two-wire 4 ma to 20 ma analog signal output (optional) C. Relay switch output (optional) d. RS485 bus output (optional) |
| Wiring Method | M 20 x 0.059 in (1.5 mm) (metric) |
| Explosion Proof Mark | Exd IIC T6 gb |
| Battery | 24 V DC or 36 V DC ±10 % |
| Alarm Method | Light or sound |
| Ambient Temperature | Temperature -40°F to 158 °F (-40 ℃ to 70 ℃) |
| Working Temperature | 50 °F to 131 °F (10 ℃ to 55 ℃) |
| Product Size | 7.2 in x 5.63 in x 4.21 in (183 mm x 143 mm x 107 mm) (display type) 7.2 in x 1.69 in x 3.62 in (183 mm x 43 mm x 92 mm) (no display type) |
