Features
- Intrinsically safe products
- The gas (Ammonia) is selective, free from other gases, water vapor, dust interference
- Detection of methane and methane-containing gas leakage at a distance of 20 meters
- Small size, light weight, easy to carry
- Low power consumption, can work for a long time
- Superior shockproof, waterproof and dustproof performance
- Fast response, large measuring range and high measuring accuracy
- It can realize data recording and Bluetooth transmission function
- Detection method harmonic laser spectrum theory
- Detection of gas NH3
- Sensor type infrared laser
- Comes with self test and calibration functions, without the need for daily calibration
Technical Specifications
| Concentration Measurement Range | (0 to 10000) ppm·m |
| Sensitivity Detection Distance | 0 m to 30 m, 5 ppm to m, 30 m to 60 m, 10 ppm to m |
| Response Time | ≤ 0.1 seconds |
| Effective Distance | 0 m to 20 m |
| Concentration Display Resolution | 1 ppm·m |
| Measurement Accuracy | ± 10 % @ 100 ppm to m (2 m) |
| Display Method | LCD |
| Outer Covering Protection Rate | IP65 |
| Intrinsically Safe | Ex ib II C T4 Gb |
| Laser Protection Class | Class IIIR |
| Working Humidity | ≤ 99 % |
| Work Pressure | 80 kPa to 116 kPa |
| Operating Voltage | 110 V AC to 240 V AC, 50 Hz or 60 Hz |
| Working Time | ≥ 10 hours |
| Power Supply | Rechargeable Lithium Battery |
| Number of Batteries | 1 pcs |
| Housing Material | ABS and PC |
| Storage Temperature | -40 °F to 158 °F (-40 °C to 70 °C) |
| Operating Temperature | -4 °F to 122 °F (-20 °C to 50 °C) |
| Host Size | 5.19 in × 2.91 in × 1.44 in (132 mm × 74 mm × 36.5 mm) |
| Host Weight | 0.79 lb (0.36 kg) |
