Features
- Double Locating as Illuminating
- Locating cross locating
- Double Measurement End Face: Large area measurement and small area
- measurement New Integrating Sphere Design: More stable measurement
- Equipped with Rechargeable High-Capacity Li-ion Battery
Technical Specifications
| Illuminating/Viewing Geometry | 8/d |
| Measuring Aperture | Φ4 mm |
| Detector | Silicon photoelectric diode |
| Locating | Illuminating Locating/Cross Locating |
| Measurement End Face | Large stable end-face and small concave-convex end-face |
| Colour Space | CIEL x a x b x C x h x CIEL x a x b x CIEXYZ |
| Colour Difference Formula | Delta E x ab delta L x a x b x E x C x h x |
| Light Source | D65 |
| Light Source Device | LED blue light excitation |
| Errors Between Each Equipment | ≤0.80 delta E x ab |
| Storage | 100 pcs standards 20000 pcs samples |
| Repeatability | Standard deviation within E x ab 0.08 Average of 30 measurements of standard white plate |
| Language | English/Chinese |
| Power Source | Rechargeable lithium-ion battery 3.7 V @3200 mAh |
| Lamp Life | 3 years, more than 1.6 million measurements |
| Charging Time | 8 % hours to 100% electricity |
| PC Software | CQCS3 Software |
| Printer (Optional) | Miniature thermal printer |
| Dimension | 8.07 in x 2.67 in x 3.14 in (205 mm × 67 mm × 80 mm) |
| Weight | 0.99 lb (450 g) |
