Name: Enviro Forest Hydrogen Sulfide Gas Detector - Enviro Forest
SKU: EFORHSGD-102

Enviro Forest Hydrogen Sulfide Gas Detector

Enviro Forest hydrogen sulfide gas detector multi gas analyzer gas analyser gas monitor system gas leak detector to measure Carbon monoxide hydrogen sulfide oxygen methane carbon dioxide CO H2S O2 CH4 CO2 gas with pump built-in.

Overview

Features

Using imported high-precision sensor
100,000 sets of data can be stored, storage interval available set, minimum 5S,
LCD can display the type of gas, the gas unit, gas concentration values etc
English operation interface
Gas concentration unit PPM, mg per m3 can quickly switch the display
Built-in micro sampling pump, the pump suction size ten stalls adjustable
Shell with high-strength special engineering plastics, non-slip, waterproof, dustproof

Technical Specifications

Gas Detected	Carbon monoxide hydrogen sulfide oxygen methane carbon dioxide CO H2S O2 CH4 CO2
Detection Principle	Catalytic combustion principles (CH4) Infrared principles (CO2)Electrochemical principles (CO, H2S, O2)
Sampling Method	Pump- suction, flow up 1L per min, pump suction size ten stalls adjustable
Data Logger	100,000 sets of data can be stored, storage interval available set, minimum 5 S, can be browsed
Measure Range	CO (0 ppm to 1000 ppm), H2S (0 ppm to 100 ppm), O2(0% VOL to 30% VOL), CH4 (0% LEL to 100% LEL), CO2 (0 ppm to 5000 ppm)
Resolution	0.1ppm (0 ppm to 1000 ppm),0.01 ppm (0 ppm to 100 ppm) 0.01% VOL (0% VOL to 30% VOL) 0.01% LEL (0% LEL to 100% LEL),1 ppm (0 ppm to 5000 ppm)
Precision	2% FS
Response Time	≤ 10 S
Repeatability	≤ ± 1%
Zero Shift	≤ ± 1% (F.S per Year)
Explosion-Proof	Exia II CT4
Alarm Mode	Sound, light, vibration
Recovery Time	≤ 10 S
Linearity Error	≤ ± 1%
Display	LCD
Gas Unit	Multiple gas unit
Humidity	0% RH to 95% RH
Degree Of Protection	IP66
Operating Time	100 hours (off pump)
Temperature	-40 °F to 158 °F (-40 ℃ to 70 ℃)
Dimensions	8.07 in x 2.95 in x 1.26 in (205 mm x 75 mm x 32 mm)
Weight	0.66 lb (0.3 kg)
