Technical Specifications
| Air Parameters | Air temperature humidity or the other can be custom made |
| Gas Module | Can be replaced |
| Load Resistance | 100 Ω |
| Stability (or year) | ≤2% FS |
| Communication Interface | RS 485 MODBUS RTU |
| Power Supply Voltage | 10 VDC to 24 VDC |
| Maximum Power Consumption | 100 mA |
| Carbon Monoxide | Range: 0 ppm to 1000 ppm Display resolution: 0.01 ppm Accuracy: 3% FS |
| Carbon Dioxide | Range: 0 ppm to 5000 ppm Display resolution: 1 ppm Accuracy: ± 75 ppm ± 10% (reading) |
| Oxygen | Range:0% to 25% VOL Display resolution: 0.01% VOL Accuracy: 3% FS |
| Methane | Range: 0 ppm to 10000 ppm Display resolution: 1 ppm Accuracy: 3% FS |
| Hydrogen Sulfide | Range: 0 ppm to 100 ppm Display resolution: 0.01 ppm Accuracy: 3% FS |
| Application Scenario | Livestock, agriculture, indoor, storage, medicine etc. |
| Transmission Distance | 1000 meters (RS 485 communication dedicated cable) |
| Material | Corrosion-resistant stainless-steel housing |
| Wireless Module | GPRS 4G WIFI LORA LORAWAN |
| Cloud Server and Software | Support to see real data in PC Mobile |
| Installation Method | Wall-mounted |
