| Display Size |
3.5 in (88.9 mm) color LCD; 320 x 240 pixels |
| Bandwidth |
20 MHz |
| Real-time Sample Rate |
50 MS/s |
| Risetime |
10 ns |
| Channels |
1 |
| Vertical Sensitivity |
50 mV to 200 V/div |
| Vertical Resolution |
8 bits |
| Trigger Mode |
Free Run, falling edge, rising edge |
| Trigger Source |
Internal |
| Trigger Coupling |
AC/DC |
| Input Impedance |
1 MΩ/200 pF |
| Max Input Voltage |
1000 V (peak) |
| Cursor Measurement |
Voltage and time/ Frequency |
| PC Interface |
Bluetooth |
| Power Supply |
6 hours Li-ion rechargeable battery; AC adaptor/charger |
| Size (H x W x D) |
8.66 in x 3.78 in x 2.36 in (220 mm x 96 mm x 60 mm) |
| Weight |
1.39 lb （631g） |
