Technical Specification
| Measuring Range | 0.3 ft (0.1 M) to 200 GΩ |
| Testing Voltage | 0.5 KV, 1 KV, 2.5 KV, 5 KV, 10 KV |
| Display Type | Digital Only |
| Accuracy Class | ±10% |
| Operating Temperature | 14 °F to 104 °F (- 10 ℃ to 40 ℃) |
| Short Circuit Current | ≥5 mA |
| Temperature Measurement | −49 °F to 257°F (- 45 ℃ to 125 ℃) |
| After Service | Yes |
| Current Test Range | 10 mA |
| Capacitance Test Range | 25 uf |
| Dimensions | 12.6 in x 10.8 in x 5.5 in (320 mm x 275 mm x 140 mm) |
| Weight | 11.02 lb (5 kg) |
