Features
- Single-chip microcomputer control, LCD Screen (128×64 Dots)
- Large LCD screen, can display multiple sets of data
- Large memory space, can store multiple sets of data and curve
- Auto zero, 100% adjustment function
- Auto wavelength adjustment
- Auto filter changing, large sample pool 0.019 in to 3.93 in (0.5 mm to 100 mm)
- With up to ten standard sample for measurement function of standard curve establish
- Switch off power save standard curve parameter measuring set
- Can be done any standard curve editor, convenient for use
- With USB interface
- More accurate and flexible measurement with PC control
Technical Specifications
| Wavelength Range | 325 to 1000nm |
| Band Width | 2 nm |
| Wavelength Accuracy | ±1.0 nm |
| Wavelength Repeatability | 0.2 nm |
| Photometric Accuracy | ±0.5% T |
| Photometric Repeatability | 0.2% T |
| Stray Light | ≤0.05% T (340 nm NaNO2) |
| Stability | 0.001 A/30min@500nm |
| Photometric Mode | Transmittance, Absorbency, Concentration, Energy |
| Wavelength Setting | Automatic |
| Photometric Display Range | -0.3A to 3A |
| Display Mode | LCD Screen (128×64 Dots) |
| Detector | Import Silicon Photodiode |
| Light Source | Import Tungsten Lamp |
| Power Requirement | AC 220 V or 50Hz 110 V or 60Hz |
| Power | 120 W |
| Dimension | 23.62 in x 17.72 in x 12.6 in (60 cm x 45 cm x 32 cm) |
| Weight | 24.25 lb (11 kg) |
