Features
- The short-circuit current can be adjusted up to 5mA.
- Excellent anti-interference performance,
- The capacitive test product is discharged quickly
- English Menu, easy operation
- Display insulation resistance simulation column
- Digital filter function
- Data storage function (USB Data export and Micro-printer)
Technical Specifications
| AC Power | 220 V ± 10 %, 50 Hz / 60 Hz，20 VA |
| Battery | 16.8 V Lithium-ion rechargeable battery |
| Battery Life | 5000 V@100 M， 6 hours |
| Dimension | 10.62 in x 9.05 in x 6.29 in (27 cm x 23 cm x 16 cm) |
| Test Voltage Accuracy | the nominal value 100 % to 110 % |
| Output Voltage Measurement Accuracy | ± 5 % ± 10 V |
| Voltage Measurement Range | AC:30 V to 600 V (50 Hz/60 Hz), DC:30 V to 600 V |
| Voltage Measurement Accuracy | ± 2 % ± 3 dgt |
| Current Test Range | 10 mA |
| Current Measure Precision | 5 % + 0.2 nA |
| Short-Circuit Current | 2 mA to 5 mA, output adjustable |
| Capacitance Test Range | 25 uF |
| Capacitance Test Accuracy | ± 10 % ± 0.03 uF |
| Protection | 2 % error, shielding 500 kΩ leakage resistance under 100 MΩ load |
| Analog Display Range | 100 kΩ to 10 TΩ |
| Digital Display Range | 100 kΩ to 10 TΩ |
| Alarm | 0.01 MΩ to 9999.99 MΩ |
