Features
- With new power supply technology, rapid measurement, compact, easy to use
- Can store max 255 groups test data
- Adopting “four-terminal” measurement method in technical
- Panel printer can quickly print measurement results
- Saved data can be reviewed and printer
Technical Specifications
| Testing Current | 1 mA, 10 mA ,1 A ,5 A |
| Testing Precision | ± (0.2 % full-scale ± 2 digital) |
| Data Storage | 255 data |
| Display | LCD Monitor |
| Highest Resolution Ratio | 0.1 μΩ |
| Power Supply | AC 230 V ± 23 V, 50 Hz ± 2 Hz |
| Maximum Power Dissipation | 200 W |
| Working Environment | Temperature: 32 °F to 104 °F (0 °C to 40 °C)Relative Humidity: ≤ 80 % |
| Volume | 7.87 in x 15.74 in x 11.02 in (200 mm x 400 mm x 280 mm) |
| Weight | 17.63 lb (8 kg) |
