Features
- Detection principle of each parameter confirms recognized method
- Imported cold light source and narrow band interface
- The absorbance of sample under specific light source
- Data automatically processed by microcomputer
- The sample concentration value is directly displayed units
- Widely used in waste water pollution index
Technical Specifications
| Determination Range | COD: 0 mg per L to 1000 mg per L, Ammonia Nitrogen: 0 mg per L to 50 mg per L, Total Phosphorus: 0 mg per L to 20 mg per L, Total Nitrogen: 0 mg per L to 1000 mg per L, Turbidity: 0 mg per L to 1000 mg per L |
| Anti Chlorine Interface | 1000 mg per L |
| Lower Detection Limit | COD: 5 mg per L, Ammonia Nitrogen: 0.1 mg per L, Total Phosphorus: 0.2 mg per L, Total Nitrogen: 0.5 mg per L, Turbidity: 0.5 mg per L |
| Measurement Error | ±5 % |
| Repeatability | ±5 % |
| Batch Throughput | 6, 16, 25 (optional) |
| Data Processing | 4000 records and 96 curves |
| Ambient Humidity | 85 % Without condensation |
| Transmission Mode | USB data cable, LAN, Bluetooth transmission, etc |
| Printer | Portable Thermal Printer |
| Optical Stability | 0.001 A or 20 min (Life span of 100.000 h) |
| Power Supply Mode | 5 V rechargeable battery |
| Power | 0.3 W |
| Digestion Environment | COD: 329 °F, 15 min (165 °C), Ammonia Nitrogen: No Digestion Required, Total Phosphorus: 257 °F, 30 min (125 °C), Total Nitrogen: 257 °F, 30 min (125 °C), Turbidity: No Digestion Required |
| Ambient Temperature | 41 °F to 104 °F (5 °C to 40 °C) |
| Host Size | 9.84 in x 3.74 in x 3.14 in (250 mm x 95 mm x 80 mm) |
| Digestion Instrument | 302.03 lb. (1.37 kg) |
