Features
- Detects up to 6 gases simultaneously
- Uses a pump to draw in gas samples from a distance
- Shows the concentrations of all 6 gases at the same time
- Color LCD screen
- Temperature compensation
- Computer export data, check the curve
Technical Specifications
| Detection gas | can accurately detect six kinds of gases such as NH3, H2S and O2 at the same time |
| Detection method | pump suction type |
| Detection principle | analytic combustion, infrared detection, electrochemistry, photon, PID, thermal conductivity |
| Accuracy | ≤ ± 3% F.S, (Actual concentration, higher accuracy is required according to sensor performance) |
| Response | Time T 90 < 30 S |
| Data storage | The standard capacity of 80,000 pieces of data supports the machine to view, delete or data export, support the upper computer to export data |
| Charger | USB powered DC 5 V |
| Charging time | ≤ 12 hrs |
| Working time | > 10 hrs (at room temperature, no alarm) |
| Power consumption | < 3 W |
| Protection class | IP 54 |
| Battery capacity | 7500 mAh lithium battery, nominal voltage: 3.7 V DC |
| Humidity range | 10% RH to 95% RH (no condensation) |
| Pressure range | 0.86 PSI to 15.37 PSI (86 kPa to 106 kPa) |
| Main material | ABS + PC |
| Temperature range | -4 °F to 122 °F (-20 ℃ to 50 ℃) |
| Size | 8.12 in x 2.75 in x 1.41 in (206.5 mm x 70 mm x 36 mm) |
| Weight | About 0.61 lb (280 g) (not including sensor) |
