Features
- Measures pX or pH, ORP, conductivity, TDS, salinity, Resistivity, dissolved oxygen, saturation and temperature
- Adopts LCD display and Chinese operation interface
- Has manual or automatic temperature compensation
- Provides zero oxygen and full-scale calibration
- When meter measures conductivity, it switches frequency automatically to guarantee measuring accuracy
Technical Specifications
| Range | |
| pH/ pX | -2.00 pH or pX to 20.00 pH or pX |
| ORP | ± 1999.9 mV |
| Conductivity | 0.000 μS/cm to 199.9 mS/cm |
| Resistivity | 0.00 Ω·cm to 20.00 MΩ·cm |
| TDS | 0.000 mg/L to 100 g/L |
| Salinity | 0.00 % to 8.00 % |
| DO | 0.00 mg/L to 19.99 mg/L |
| DO Saturation | 0.0 % to 199.9 % |
| Response Time | ≤45 s (90 % respond at 68 °F (20 ℃)) |
| Ion Concentration | (0 to 19990), unit: ug/L, mg/L, g/L,l mol/L, mmol / L |
| Resolution | |
| pH/ pX | 0.01 |
| ORP | 0.1 mV |
| Conductivity | 0.001 μS/cm |
| Resistivity | 0.01 Ω·cm |
| TDS | 0.001 mg/L |
| Salinity | 0.01 % |
| DO | 0.01 mg/L |
| DO Saturation | 0.10 % |
| Accuracy | |
| pH/ pX | ± 0.01 pH ± 1 bit |
| ORP | ± 0.1 % FS |
| Conductivity | ± 1.0 % FS |
| Resistivity | ± 1.0 % FS |
| TDS | ± 1.0 % FS |
| Salinity | ± 0.2 % |
| DO | ± 0.30 mg/L |
| DO Saturation | ± 10.0 % FS |
| Data Storage | 200 data with time and date stamp |
| Display | LCD |
| Output | RS-232 |
| Software | 1.1DC |
| Power | Universal power adapter (9 V DC, 800 mA) |
| Temperature | 0.3 °F (± 0.3 ℃) ± 1 bit 0.1 °F (0.1 ℃) 23 °F to 221 °F (-5.0 °C to 105.0 ℃) |
| Temperature Compensation | Auto, pH: 32 °F to 212 °F (0 °C to 100 °C) Conductivity: 32 °F to 212 °F (0 °C to 100 °C) DO: 32 °F to 104 °F (0 °C to 40 °C) |
