Features
- Calibration Due Reminder prompts user to calibrate the meter regularly
- Stability indicator shows when a measurement is recognized as stable
- Auto Hold feature senses and locks the measurement endpoint
- Setup menu allows setting the 10 parameters, including the number of calibrations
- points, resolution, stability criteria, temperature unit, auto power off, etc
- Reset feature automatically resumes all settings back to factory default options
- Expanded memory stores and recalls up to 500 data sets
- Stored readings can be transferred into the computer by USB communication interface
- Multi mode power scheme (batteries, power adapter or USB port) ensures that use the meter smoothly
Technical Specifications
| PH Range | -2.000 pH to 20.000pH |
| Accuracy | ± 0.002 pH |
| Resolution | 0.1, 0.01, 0.001pH, selectable |
| Calibration Points | 1points to 5 points |
| pH Buffer Options | USA, NIST, DIN or Custom |
| mV Range | ± 1999.9 mV |
| Accuracy | ± 0.2 mV |
| Resolution | 0.1, 1mV, selectable |
| Calibration Points | 1 point |
| Measurement Modes | Relative or Absolute mV |
| Ion Range | 0.001 to 19999 (Depending on the range of ISE) |
| Accuracy | ± 0.5 % F.S (Monovalent), ± 1 % F.S (Divalent) |
| Resolution | 0.001, 0.01, 0.1, 1 |
| Calibration Points | 2 points to 5 points (0.001, 0.01, 0.1, 1, 10, 100, 1000, 10000) |
| Calibration Solutions | 0.001, 0.01, 0.1, 1, 10, 100, 1000, 10000 ppm, mg per L, mol per L, mmol per L |
| Calibration Points | 1 point |
| Data Hold | Manual or Auto Endpoint |
| Stability Criteria | Low or High |
| Calibration Due Alarm | 1 day to 31 days or off |
| Power Off | Manual or Automatic (10, 20, 30 minutes) |
| Memory | Stores up to 500 data sets |
| Output | USB communication interface |
| Connector | BNC |
| Display | LCD |
| Power | 3 × 1.5 V AA batteries or DC 5 V power adapter |
| Battery Life | Approximately 150 hours (Turn off the backlit) |
| Temperature Compensation | 32 °F to 212 °F (0 °C to 100 °C) Manual or Automatic |
| Calibration Range | Measured value 50 °F (± 10 °C) |
| Temperature Range | 32 °F to 221 °F (0 °C to 105 °C,) |
| Dimensions | 6.69 in x 3.34 in x 1.18 in (170 mm × 85 mm ×30 mm) |
| Weight | 0.66 lb. (0.3 kg) |
