Features
- Combo Satellite TV Finder with DVB-S or S2+T or T2+C for Spectrum Analysis
- HD Input Function Support 800 p x 480 p to Max 1920 p x 1080 p
- AHD Input Function
- Automatically Display HD AHD or TVI or CVI Camera Pixel
- Support TVI AHD CVI camera 720P 960P 1080P HD video input
- Display picture (Max:8MP) and Support Analog CVB-S Video
- Support DVB-S or S2 MPEG-4 HEVC (H.265) AVS or AVS+
- With DC 12 V power output to CCTV Camera
- Multi-Languages Menu in English, Arabic, French, German, Russian, Spanish, Turkey
- On Satellite Finder State USB connection Internet, YouTube or Weather or LOCAL IPTV
- Built- In Rechargeable Lithium Battery easy for outdoor use.
Technical Specification
| Screen Size | 7 in (17.78 cm) IPS Panel |
| Dot Pixels | 1024 pixels x 600 pixels |
| Color System | PAL or NTSC |
| DVB-S or S2 Frequency Range | 950 MHz to 2150 MHz |
| LNB Power & Switch | 13 V 18 V or 22K or signal lock indicator |
| Input Impedance | 75Ω (F) |
| DiSEqC | 1.0, 1.1, 1.2, USALS |
| DVB-T or T2 Frequency Range | VHF-H 174 MHz to 230 MHz, UHF 470 MHz to 860 MHz |
| DVB-T/T2 Demodulation | QPSK, 16QAM, 64QAM,256QAM |
| DVB-T/T2 Band Width | 6,7,8 MHz |
| DVB-C Frequency Range | 115 MHz to 858 MHz |
| DVB-C Symbol Rate (Kbps) | Modify according to local country information |
| DVB-C Demodulation | 16QAM, 32QAM, 64QAM,128QAM,256QAM |
| Lithium Battery | DC 11.1V 2600 mAh (built-in) |
| Unit Size | 7 in x 5.6 in x 1.9 in (180 mm x 143 mm x 50 mm) |
| Unit Weight | 1.3 lb (590 g) (including battery pack) |
