Features
- 90 ° angle scattered light principle, built-in temperature sensor
- Supports RS-485, Modbus / RTUprotocol
- Fiber structure, external light anti-interference ability
- Infrared LED light source, high stability
- IP68 protection class.The water depth is within 20 meters
- Convenient, fast, stable, easy to maintain
Technical Specifications
| Measuring principle | Light scattering method |
| Measuring range | 0 NTU to100 NTU or 0 NTU to 1000 NTU |
| Resolution | 0.01 NTU,0.1 ℃ |
| Accuracy | ±3 % or ≦±3 NTU, is subject to the larger, ±0.5 ℃ |
| Calibration methods | Two-point calibration |
| Temperature compensation | Automatic temperature compensation (Pt1000) |
| output method | RS-485 (Modbus / RTU) |
| Working conditions | 0 ℃ to 50 ℃, <0.2 MPa |
| Storage temperature | -5 ℃ to 65 ℃ |
| Mounting | Immersion installation |
| Power | 12 V |
| Power supply | 12 V to 24 V DC |
| Protection class | IP68 |
