Overview
Enviro Forest triaxial vibration spectrum analyzer has a 2-in-1 functionality to measure Hand-Arm and Whole Body; vibration in compliance with ISO 5349, ISO 2631 and the EU Directive 2002 or 44 or EC; easy to use – no complicated set-up and remembers your settings for next time. It stores up to 10,000 measurements Integrated Frequency Analysis (FFT), includes a reporting package for easy data analysis and reporting. They provide a simple and convenient way to measure, analyze and assess vibration data in accordance with standards such as ISO 5349 and European Directive 2002 or 44 or EC.
Technical Specifications
| Human Vibration | Interval RMS, vector sum, peak value |
| Frequency Analysis | 125 lines for X, Y, Z, peak spectrum of acceleration |
| Acceleration | 0.1 Hz to 2000 Hz or 1 Hz to 1000 Hz |
| Velocity | 1 Hz to 100 Hz or 2 Hz to 1000 Hz or 10 Hz to 1000 Hz |
| Displacement | 5 Hz to 250 Hz |
| Linearity Range | >75 dB for ±6% error |
| Temperature | -4 ⁰F to 140 ⁰F (-20 °C to 60 °C) |
| Sensitivity | 0.8 mV or ms-2 |
| Display | Color OLED |
| Power | 3 x AAAAlkaline LR03Typically, 10 to 14 hours operation |
| Dimension | 4.92 in x 2.56 in x 1.06 in (125 mm x 65 mm x 27 mm) |
| Weight | 0.309 lb (140gms) |
