Features
• Large-screen color LCD display
• Intelligent menu operation
• Data Recording & Curve Display
• Manual or automatic temp. compensation
• Three sets of relay control switches
• High alarm & low alarm, hysteresis control
• 4 to 20 mA & RS485 Multiple output modes
• Turbidity value, temperature & current value are simultaneously displayed in one screen
• Password protection function to prevent mis operation by non-staff
Technical Specifications
| Measuring Range: | 0.001 to 9999 NTU |
| Temperature: | 32 °F to 122 °F (0 °C to 50 °C) |
| Unit Selected: | NTU |
| Resolution | |
| Turbidity: | 0.001 NTU |
| Temperature: | 32.18 °F (0.1 °C) |
| Intrinsic Error | |
| Turbidity: | ± 1 % F.S. |
| Temperature: | 32.54 °F (± 0.3 °C) |
| Current Outputs | |
| Output Range: | 0/4 to 20 mA |
| Load Resistance: | < 750 Ω |
| Communication Output: | RS485 MODBUS RTU |
| Sets of relay contacts | |
| Contact Rating: | 5 A 250 V AC, 5 A 30 V DC |
| Power supply | |
| Voltage Range: | 85 V AC to 265 V AC ± 10 %, 50 ± 1 Hz |
| Power Consumption: | ≤ 3 W |
| Voltage Range: | 9 V DC to 36 V DC |
| Power Consumption: | ≤ 3 W |
| Dimensions: | 5.6 in x 5.6 in x 4.6 in (144 mm x 144 mm x 118 mm) |
| Installation | |
| Mounting Options: | Panel, Wall Mounting, Pipeline |
| Panel Opening Size: | 138 mm x 138 mm |
| Waterproof Rating: | IP65 |
| Weight: | 1.7 lb (0.8 kg) |
| Working environment | |
| Operating Temperature: | 14 °F to 140 °F (-10 °C to 60 °C) |
| Relative Humidity: | ≤ 90 % |
