Overview
This fixed gas detector is designed for reliable monitoring of methane (CH4), propane (C3H8), butane (C4H10), and natural LPG. It ensures accurate detection to prevent potential gas leaks and hazards, making it suitable for industrial, commercial, and residential environments. With advanced sensing technology, it delivers stable performance and quick response times. The detector is built with a durable structure to withstand tough conditions while maintaining consistent accuracy. Easy to install and maintain, it provides continuous protection and helps ensure workplace and home safety.
Features
- Provides accurate and fast detection to prevent gas leak risks.
- Detects methane (CH4), propane (C3H8), butane (C4H10), and natural LPG.
- Strong and durable design for long-term use.
- Suitable for industrial, commercial, and residential applications.
- Easy installation and low maintenance requirements.
- Continuous real-time monitoring for reliable safety.
- Stable performance even in tough environments.
Technical Specifications
| Parameter | Value |
| Working Voltage | DC 24V power supply |
| Output Signal | 4 to 20mA |
| Communication | RS485 (Protocol: ModBus RTU) |
| Passive Switch Output | Maximum capacity: 250V, 2A |
| Connection Thread | M20 × 1.5 internal thread, G3/4 (optional) |
| Relative Humidity | 10 to 93% RH (non-condensing) |
| Atmospheric Pressure | 86 kPa to 106 kPa |
| Installation Conditions | Place without significant impact/vibration; avoid corrosive/damaging media |
| Product Size (L × W × H) | 185 × 143 × 82 mm (7.28 × 5.63 × 3.23 in) |
| Operating Environment | -40°C to +70°C (-40°F to +158°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Protection Rating | IP65 (dust-tight and protected against water jets) |
| Material / Enclosure | High-strength ABS / Polycarbonate |
| Response Time | < 1 second (typical for output signal) |
| Accuracy | ±0.5% of full scale |
| Power Consumption | < 2W |
| Electromagnetic Compatibility (EMC) | EN 61326-1:2013 |
| Mounting Type | Wall-mounted or Panel-mounted |
| Display / Indicators (Optional) | LED indicators for power, communication, and alarm status |
