| Specification |
Details |
| Accuracy |
±1% of reading at rates >0.2 mps |
| Repeatability |
0.2% |
| Principle |
Transit-time |
| Velocity |
up to 32 m/s |
| Pipe Size |
DN15mm to DN6000mm |
| Display |
LCD with backlight, shows accumulated flow/heat, instantaneous flow/heat, velocity, time |
| Signal Output |
4-20mA, OCT pulse, relay |
| Signal Input |
3x 4-20mA for heat measurement with PT100 |
| Functions |
Records forward/reverse/net flow and heat, power-on/off times, last 30 readings, data via Modbus |
| Pipe Material |
Carbon steel, stainless steel, cast iron, cement, copper, PVC, aluminum, FRP; liner allowed |
| Straight Pipe Section |
Upstream 10D, Downstream 5D, From pump 30D |
| Liquid Types |
Water, sea water, industrial sewage, acid/alkali, alcohol, beer, oils that transmit ultrasonic waves |
| Liquid Temperature |
Standard -30°C to 90°C, High-temp -30°C to 160°C |
| Liquid Turbidity |
<10000ppm, minimal bubbles |
| Flow Direction |
Bi-directional, net flow/heat |
| Environment Temp |
Main -30°C to 80°C, Transducer -40°C to 110°C |
| Humidity |
Main 85% RH, Transducer IP65 (IP68 optional) |
| Cable |
Twisted pair, 5m standard, extendable to 500m; RS485 up to 1000m |
| Power Supply |
AC220V or DC24V |
