Features
- High accuracy low resistance measurement with ±0.1% FS precision
- Auto calibration and wide measurement range up to 300 kΩ
- Multiple selectable test currents from 0.05 mA to 1.2 A
- Resolution down to 0.001 mΩ for precise micro-ohm measurement
- Compact and portable design with durable electronic power system
- Large LCD display with easy-to-read results
- Suitable for transformer windings, conductors, and industrial applications
Technical Specifications
| Measuring Range | 0.001 mΩ to 300 kΩ |
| Accuracy | ±0.1% FS ± 20 digits |
| Resolution | 0.001 mΩ to 0.1 kΩ (depending on range) |
| Maximum Test Current | 1.2 A (varies by range) |
| Measuring Range | 0.01 mΩ to 30 kΩ |
| Accuracy | ±0.1% FS ± 20 digits |
| Resolution | 0.01 mΩ to 0.01 kΩ (depending on range) |
| Output Current Options | <5 mA, 0.05 mA, 0.5 mA, 5 mA, 0.05 A, 0.5 A, 1.2 A |
| Display | Digital LCD |
| Supply Power | Electronic |
| Operating Temperature Range | 32 °F to 104 °F (0 °C to 40 °C) |
| Humidity Range | <90% RH, non-condensing |
| Dimensions | 15.7 in x 8.9 in x 13.8 in (40 cm x 22.5 cm x 35 cm) |
| Product Weight | 28.7 lb (13 kg) |
