Features
- High-precision measurements with 120,000 counts resolution
- Wide applications for wires, transformers, motors, and shunt resistors
- Temperature drift ±100 ppm for stable readings
- Built-in 18650 rechargeable battery with USB charging
- Supports resistivity, length, and cross-sectional area calculations
- Compact, portable, and optimized for field or lab testing
Technical Specifications
| Resolution | 120,000 counts |
| Measuring Range | 0.01 mΩ to 1 kΩ |
| Accuracy | 1 Ω gear: ± (0.12% + 0.03%) 10 Ω gear: ±(0.08% + 0.02%) 100 Ω gear: ± (0.08% + 0.02%) 1 kΩ gear: ±(0.10% + 0.03%) |
| Minimum Resolution | 0.01 mΩ |
| Temperature Drift | ±100 ppm (50 °F to 104 °F / 10 °C to 40 °C) |
| Battery Type | Built-in 18650 rechargeable battery |
| Charging Method | USB charging (compatible with Android chargers) |
| Applications | Wire resistivity testing, transformer winding check, motor repair, power cord analysis, connector contact resistance, shunt testing |
| Safety Warning | Do not measure live circuits |
| Operating Temperature | 50 °F to 104 °F (10 °C to 40 °C) |
| Storage Environment | Dry, non-corrosive, and dust-free environment |
| Weight | 1.1 lb (0.5 kg) |
