Overview
Enviro Forest vibration sensor is mainly designed for industrial, commercial, and general building vibration detection and control. It is suitable for various kinds of large and medium-sized rotating machinery and moving equipment such as fans, water pumps, reducers, bearing blocks, rolling friction bodies, etc. for direct measurement of vibration safety and temperature rise applications.
Technical Specifications
| Sensitivity | 50 mv / g |
| Acceleration range | ±100 g |
| Frequency range (±10%) | 0.5 Hz to 5000 Hz |
| Resolving power | 1 mg |
| Frequency response | Up to 15 kHz |
| Transverse sensitivity | ≤5% |
| Excitation voltage | 18 VDC to 28 VDC |
| Exciting current | 2 mA to 10 mA |
| Output bias voltage | 11 ±1 VDC |
| Output impedance | <100 Ω |
| Housing material | Titanium alloy |
| Sensitive parts | Ceramics, shear |
| Operating temperature | -40 °F to 249.8 °F (-40 °C to 121 °C) |
| Weight | 0.11 lb (50 g) |
