Overview
This gas detector is an essential safety device for any kitchen. It is designed to be a multi-functional unit, capable of sensing both methane (CH4) and LPG (liquefied petroleum gas), which are common household gases. The system features a built-in alarm that triggers immediately upon detecting a leak, providing a fast and reliable warning. By continuously monitoring the air, it helps to prevent potential fires and explosions, ensuring the safety of your home and family. It’s a simple yet critical component for modern kitchen safety.
Features
- It is a safety device for your kitchen.
- It can find two common gases: methane (natural gas) and LPG (propane).
- The detector has a built-in alarm that goes off as soon as it finds a gas leak.
- It is a single unit that performs more than one job, making it a “multi-functional” tool.
- By continuously checking the air, it helps to prevent fires and explosions.
- It is a simple and important device to help keep your home safe.
Technical Specifications
| Detection Principle | Semiconductor type sensor |
| Gas Type Detected | Methane (Natural Gas), Propane (LPG) |
| Detection Range | 0 to 25% Lower Explosive Limit (LEL) |
| Alarm Threshold | 8% LEL or 10% LEL (configurable) |
| Response Time (T90) | ≤30 seconds |
| Alarm Mode | Audible and visual (sound and light) |
| Power Supply | AC 220V ±15% (50Hz) |
| Power Consumption | Approximately 1.5W (typical) |
| Installation | Wall-mounted |
| Operating Temperature | -10°C to +50°C |
| Operating Humidity | <95% Relative Humidity (non-condensing) |
| Alarm Sound Level | ≥85 dB at 3 meters |
| Relay Output | Optional, for integration with external systems |
| Dimensions (L × W × H) | 150 × 100 × 50 mm (5.9 × 3.94 × 1.97 inches) |
| Weight | 1.000 kg (2.2 lb) |
| Material | Flame-retardant ABS plastic |
| Certification | CE (Conformité Européenne) |
| Mounting Type | Wall-mounted with included bracket |
| LED Indicators | Power on, gas detection, alarm status |
| Warranty | Typically 1 year (check with supplier) |
Reviews
There are no reviews yet.
