Overview
This Methane Gas Detector is designed to monitor methane leaks in underground valves and wells with high accuracy. Equipped with an advanced laser sensor, it detects even small gas concentrations to prevent potential hazards. The device features a real-time alarm system to alert operators instantly when dangerous levels are detected. Powered by a reliable lithium battery, it ensures continuous monitoring in remote or hard-to-access locations. Its compact and robust design makes it suitable for industrial and utility applications. Easy to install and operate, this detector enhances safety and efficiency in methane leak management.
Features
- Detects methane leaks in underground valves and wells with high accuracy.
- Advanced laser sensor ensures detection of low gas concentrations.
- Real-time alarm system provides instant alerts for safety.
- Powered by a reliable lithium battery for continuous monitoring.
- Compact and robust design suitable for industrial and utility use.
- Easy to install and operate in remote or hard-to-access locations.
- Enhances workplace safety and efficiency by preventing gas hazards.
Technical Specifications
| Parameter | Value |
| Gas Detection | CH4 |
| Detection Principle | Laser |
| Sampling Interval | Default 30 min (adjustable) |
| Detection Range | 0 to 100% LEL |
| Indication Error | ±3% LEL |
| Alarm Concentration | 20% LEL (configurable) |
| Response Time | ≤ 30 s |
| Protection Level | IP68 |
| Working Voltage | 3.6 V (Lithium-thionyl chloride battery) |
| Battery Life | ≥ 36 months |
| Operating Humidity | ≤ 98% RH (non-condensing) |
| Data Storage | 1600 gas concentration records, 1000 alarm records; stores data for nearly one month |
| Historical Data Export | Bluetooth 5.2, supports SPP, GATT, HID protocols |
| Alarm Method | Cloud platform upload |
| Installation Method | Buried installation, post-mounted installation |
| Vibration Monitoring | ≤ 25 m |
| Operating Temperature | -40 to 70 °C (-40 to 158 °F) |
