Features
- Pen style design with clip for easy portability
- 6000 counts auto-ranging display
- Measures AC/DC voltage up to 600 V
- Resistance measurement up to 60 MΩ
- Capacitance measurement up to 2 mF
- Frequency measurement up to 100 kHz
- NCV and live line detection
Technical Specifications
| Measuring Voltage Range | AC/DC; 0.6 V to 600 V |
| Measuring Resistance Range | 6 kΩ to 60 MΩ |
| Measuring Capacitance Range | 100 nF to 2 mF |
| Measuring Frequency Range | 0.1 Hz to 100 kHz |
| Display Counts/Digits | 6000/5999 |
| Measurement Mode | Auto-ranging or Manual-ranging |
| Display Method | LCD with backlight |
| Additional Functions | NCV detection, live line detection, diode test, continuity test, voice broadcast, data hold, auto power off, flashlight |
| Power Source | Built-in 200 mAh rechargeable lithium battery |
| Charging Time | About 2 hours |
| Operating Time | Over 8 hours continuous use |
| Operating Temperature | 32 °F to 104 °F (0 °C to 40 °C) |
| Product Weight | 0.55 lb (250 g) |
| Product Size | 0.91 in x 0.91 in x 6.69 in (2.3 cm x 2.3 cm x 17 cm) |
