Features
- Measures insulation resistance up to 20GΩ for comprehensive testing
- Adjustable testing voltage options: 100V, 250V, 500V, 1000V, and 2500V
- Digital display ensures quick, accurate, and clear readings
- Supports AC voltage measurement up to 750V for versatile use
- Built-in DAR function for advanced insulation diagnostics
- Compact and portable design for field and laboratory applications
Technical Specification
| Type | Testing machine |
| Display Type | Digital |
| Testing Voltage | 100V, 250V, 500V, 1000V, 2500V |
| Measuring Range | Up to 20GΩ |
| Voltage Output | 100V, 250V, 500V, 1000V, 2500V |
| AC Voltage Measurement | Up to 750V |
| Short-Circuit Current | <2mA |
| DAR Function | 60s/15s and 60s/30s |
| Power Supply | 1.5V battery (LR6) × 6 |
| Protection Class | IP55 |
| Accuracy Class | 0% to 10% |
| Dimensions | 5.91 in x 3.94 in x 2.80 in (150mm x 100mm x 71mm) |
