Features
- Tag test equipment for laboratories, label production, and engineering sites
- Lightweight design, easy to carry
- Supports 840 MHz to 960 MHz frequency range
- Tag chip type identification
- Synchronized testing of EPC+TID
- Save baseline tag curves for easy comparison of target tags
- Built-in broadband antenna for quick testing
- Supports external antenna for flexible applications
- Comes with a built-in screen for easy viewing of data
- Built-in 4000 mAh rechargeable battery, can operate continuously for over 3 hours
- Supports USB port communication and charging
Technical specifications
| Frequency Range | 840 MHz to 960 MHz |
| Rated Power | -20 to 25 dBm |
| Battery Capacity | 4,200 mAh |
| Charging Voltage/Current | 5 V / 2,000 mA |
| EPC+TID Reading | Supported |
| Tag Model Identification | Supported |
| Antenna | Built-in + External |
| Base Curve Recording | Supported |
| Body Material | Aluminum alloy |
| LCD Display | 4.3 in LCM |
| External Antenna Interface | SMA female connector |
| Communication and Charging Interface | USB Type-C |
| Operating Temperature | 32 °F to 104 °F (0 °C to 40 °C) |
| Storage Temperature | -4 °F to 140 °F (-20 °C to 60 °C) |
| Relative Humidity | 10% RH to 90% RH |
| Dimensions (L×W×H) | 6.61 in × 5.43 in × 1.77 in (168 mm × 138 mm × 45 mm) |
| Weight | 1.82 lb (825 g) |
