Features
- Handheld and portable design for easy use
- High accuracy: ±1% with excellent repeatabilit
- Supports RS232 output for data transfer
- Suitable for single medium liquids
- User-friendly interface and operation
- OEM customization and branding available
- Durable for industrial applications
Technical Specification
| Parameter | Specification |
| Host | Standalone unit |
| Principle | Transit-time ultrasonic flowmeter |
| Accuracy | ±1% |
| Signal Output | 1 way 4 to 20mA output, electric resistance 0 to 1K, accuracy 0.1% (optional) |
| Display | 2 x 20 character LCD with backlight, supports Chinese, English, and Italian |
| Signal Input | 3 way 4 to 20mA input, accuracy 0.1% |
| Data Interface | Insulated RS485 serial interface, software upgrade via computer, MODBUS supported |
| Special Cable | Twisted-pair cable, standard length under 164 ft (50 m) |
| Pipe Installation Condition | Pipe Material: Steel, Stainless steel, Cast iron, Copper, Cement pipe, PVC, Aluminum, Glass steel. |
| Measuring Medium | Medium: water, sea water, alcohol, acid and alkali, wastewater, beer, all kinds of oil |
| Work Environment | Protection grade: Host IP67, Flow sensor IP68 Humidity: Host 85% RH |
| Temperature | Host -4 to 140 °F (-20 to 60 °C); Flow sensor -22 to 320 °F (-30 to 160
°C) |
| Weight | 3.31 lb (1.5 kg) |
| Size / Dimension | 5.91 in x 3.15 in x 1.97 in (150 mm x 80 mm x 50 mm) |
