Features
- Full auto range measurement
- Measures AC/DC voltage up to 600 V
- Measures AC/DC current up to 10 A
- Resistance measurement up to 20 MΩ
- NCV and live line detection
- Continuity testing and diode test
- Data hold function
- Auto power off for battery saving
Technical Specifications
| Measuring Voltage Range | AC or DC: 0 V to 600 V ± (1.0% reading + 5 digits) |
| Measuring Current Range | AC or DC: 0 A to 10 A ± (2.0% reading + 10 digits) |
| Measuring Resistance Range | 0 Ω to 20 MΩ ± (1.2% reading + 5 digits) |
| Display Counts | 2000 counts |
| Display Method | FSTN LCD with backlight |
| Additional Functions | NCV detection, live line detection, continuity test, data hold, auto power off, flashlight |
| Power Supply | Built-in 200 mA rechargeable battery |
| Operating Temperature | 32 °F to 104 °F (0 °C to 40 °C) |
| Product Size | 2.64 in x 1.14 in x 5.20 in (6.7 cm x 2.9 cm x 13.2 cm) |
| Product Weight | 0.25 lb (115 g) |
