Overview
Enviro Forest’s Wi-Fi, Ethernet for Asset Monitoring is mainly used for communicating with devices with function, and uploading device data to the cloud, or download cloud data to device. This gateway support cellular (3G/4G), WiFi , WiFi hoppen, or Ethernet network connection. It can be powered by DC 5V or POE (802.3af). It support Bluetooth 5.0/4.2/4.1/4.0 and newer, e.g BLE sensor, iBeacon/Eddystone beacon, smart wristband, smart heart rate band.
Features
- Support Wi-Fi / Ethernet / Cellular
- Support iBeacon/Eddystone/Kensor and other device
- Support HTTP/HTTPS, MQTT/TLS MQTT
- Powerful network diagnostics
- Hardware level WatchDog ensure 24-hours full time data upload
- Optional 4G LTE module & GPS module
- Web portal for configuration
- CE/FCC certified
Technical Specifications
| Material | Industry use plastic |
| Scanning Ability | >260 beacons per second |
| Indicator | RGB LED indicator |
| Working Temp | -40 °F to 158 °F (-40 °C to +70 °C) |
| Transmitting Way | Cellular (USB dongle for 3G/4G), ETH RJ45, WiFI, WiFi hoppen. |
| Transmitting Protocol | HTTPS MQTT |
| Waterproof | IP53 with smart outdoor design |
| BLE Chipset | nRF528 series |
| Storage Temp | 50 °F to 77 °F (10 °C to +25 °C), ≤65 % RH |
| Weight | 5.29 oz (150 g) |
| Size | 6.8 in x 3.5 in x 1.7 in (173 mm x 90 mm x 45 mm) |
