Overview
Enviro Forest Smart Wi-Fi Single Phase Clamp Meter with Energy Monitoring helps you monitor the amount of electricity usage in your facility by connecting the clamp on to the power cable. It can also measure Voltage, Current, Power Factor, Active Power.
Features
- Support automation with another Tuya device
- Single phase electricity compatible
- Measures real-time Energy Usage, Voltage, Current, Power Factor
- Support Energy Production measurement
Technical Specification
| Accuracy Class | 1.0 |
| Output Voltage | 90 V AC to 250 V AC, 50 Hz or 60 Hz |
| Wi-Fi | 802.11 B/G/N20/N402.4GHz |
| Din Rail | 1.37 in (35 mm) |
| Calibrated Metering Accuracy | ≤ 100 W Within ± 2 W >100 W Within ± 2 % |
| Clamp cable length | 3.28 ft (1 m) |
| CT Provided | CT 80 A (default) CT 120 A or 200 A or 300 A(optional) |
| Reporting Cycle | Every 15 s |
| Material | Plastic |
| RF Characteristics | Operating frequency: 2.4 GHz Internal Antenna |
| Clamp diameter | 80 A (default): 0.41 in (10.6 mm) 120 A (optional): 0.65 in (16.7 mm) |
| Temperature: | -4 °F to 131 °F (-20 ℃ to 55 ℃) |
| Humidity: | ≤ 90 % non-condensing |
| Weight | 0.18 lb (85 g) 0.33 lb (150 g) |
