Features
- Portable and lightweight design for easy use
- Precision four wire measurement method for accuracy
- Wide resistance range: 0.1 mΩ to 40.0 kΩ
- High resolution down to 0.1 mΩ
- Large LCD display with backlight for dim environments
- Automatic zeroing function
- Data storage up to 1000 groups, no data loss on power-off
- Quick measurement time: 1 second per test
- Automatic shutdown after 10 minutes of inactivity
- Overload and overflow protection with “OL” display
- Low battery voltage indication
- Complies with IEC61010 safety standards
Technical Specifications
| Measuring Range | 0.1 mΩ to 40.0 kΩ |
| Resolution | 0.1 mΩ |
| Accuracy | ±0.3% ±4 dgt |
| Test Method | Precision four-wire method
2-channel A/D detection |
| Test Current | 100 mA (400 mΩ range)
0.08 mA (40 kΩ range) |
| Measuring Time | 1 second per test |
| Data Storage | 1000 groups (no loss on power down) |
| Display Type | Analogue and digital LCD with backlight |
| Automatic Functions | Zeroing and shutdown (10 minutes inactivity) |
| Power Supply | 6 x 1.5 V LR6 alkaline batteries |
| Operating Current | 100 mA max |
| Operating Temperature | 14 °F to 104 °F (-10 °C to 40 °C), ≤ 80% RH |
| Storage Temperature | 14 °F to 140 °F (-10 °C to 60 °C), ≤ 70% RH |
| Safety Protection | AC 3700 V/rms insulation between housing and screws |
| Dimensions | 6.26 in x 3.94 in x 2.60 in (15.9 cm x 10 cm x 6.6 cm) |
| Weight | 1.01 lb (460 g) |
