Features
- LCD display 6000-digit
- True RMS accuracy for precise readings
- Auto-ranging functionality
- Measures AC/DC voltage up to 600 V
- Measures AC/DC current up to 10 A
- Resistance measurement up to 60 MΩ
- Capacitance measurement up to 60 mF
- Frequency and duty cycle measurement
Technical Specifications
| Measuring Current Range | 6000 μA to 10 A |
| Measuring Voltage Range | 600 mV to 600 V |
| Measuring Resistance Range | 600 Ω to 60 MΩ |
| Measuring Capacitance Range | 6 nF to 60 mF |
| Temperature Range | -4 °F to 1832 °F (-20 °C to 1000 °C) |
| Display Method | LCD |
| Display Counts | 6000 counts |
| Measurement Mode | Auto-ranging |
| Additional Functions | True RMS, frequency measurement, duty cycle, diode testing, conductance, low battery indicator |
| Operating Temperature | 32 °F to 104 °F (0 °C to 40 °C) |
| Product Size | 5.90 in x 3.94 in x 1.42 in (15 cm x 10 cm x 3.6 cm) |
| Product Weight | 0.55 lb (250 g) |
