Overview
Enviro Forest’s Compact 40m IP54 Laser Distance Sensor with TTL Output for Industrial Use For Industrial Smart Systems The IP54 Shell 27mm Parking Distance Sensor is a high quality industrial smart system sensor that is designed to provide accurate distance measurements in a wide range of applications. This Small Size Laser Distance sensor is designed to be used in parking systems, industrial automation applications, and other smart systems that require accurate distance measurements. The Accurate Laser Distance sensor features a compact and rugged design that makes it ideal for use in harsh industrial environments. It has an IP54-rated shell that protects it from dust and water making it suitable for use in outdoor applications The 40m distance sensor also features a TTL interface that allows it to be easily integrated into a wide range of systems The TTL laser distance sensor is capable of measuring distances up to 40m with high accuracy, making it ideal for use in applications that require precise distance measurements. It uses laser technology to measure distances, which provides highly accurate results even in challenging environments IP54 Laser Distance Sensor Shell is a reliable sensor that is ideal for use in a wide range of industrial smart systems. Its compact size, rugged design, and high accuracy make it an excellent choice for applications that require precise distance measurements.
Features
- JRT module responds quickly with high accuracy and long range measuring
- We have been in this laser line for over 19 years leading supplier of laser distance meter modules in China
- 30m 40m 60m 80m 100m 120m 150m, each distance can be multi-functional
- Voltage can be changed by power converter LDO
- Operating temperature -10 ℃ to 50 ℃ can be customized
- Analog can be customized
Technical Specifications
| Measurement Range | 0.0011 in to 1.5 in (0.03 m to 40 m) |
| Measurement Accuracy | +/- .039 in (+/-1 mm) |
| Measurement Unit | Meter |
| Measurement Time | 0.4 s to 4 s |
| Laser Class | Class II |
| Laser Type | 620 nm to 690 nm, <1 mW |
| Frequency | 3 Hz |
| Voltage | DC 2.0 V to 3.3 V |
| Working Temperature | 32 °F to 104 °F (0 ℃ to 40 ℃) |
| Storage Temperature | -13 °F to 140 °F (-25 ℃ to 60 ℃) |
| Size | 1.77 in x .98 in x .47 in (45 mm x 25 mm x 12 mm) |
| Weight | 0.31 oz (9 g) |
